Drainage plans for your property

Use our interactive map to find your property and see public utility pipelines and waterways.

Request a drainage plan

This map can also be viewed in fullscreen mode(external link). Use the back button in your browser to return to this page.

Please note the following section of content is possibly being delivered from an external source (IFRAME in HTML terms), and may present unusual experiences for screen readers.

Legend

Utilities Water supply Waste water Storm water

Private drainage plans

You can request a plan by:

The Council can supply private drainage plans up to 1:500 scale. A private drainage plan might include:

  • Public and private sewer pipes
  • Public and private stormwater pipes
  • Open waterways that have been located on-site and plotted or electronically recorded from field surveys
  • Water supply pipelines up to the property’s water meter. The Council does not hold records on water supply pipe locations within private property boundaries.

Requests made in person are processed immediately. Phone requests are processed within 24 hours (weekdays only) and will be emailed to you.

Fees

Please note there is a cost for private drainage plans. See city water and waste fee schedule for current pricing.

Building over Council-owned drains

If you are rebuilding a house or garage you must check your plans don’t involve building over a Council drain.

The Council's Stormwater and Land Drainage Bylaw 2022 and Water Supply and Wastewater Bylaw 2022 specify the proximity of building work near drains – including public water, wastewater and stormwater pipes. This is so the Council can check, repair and replace drains quickly and efficiently.

Please see building near the water and wastewater network for more information.
